Waterproof Mortar Automatic Weighing And Packing Machine With Single / Double Mouth

Ask Lasest Price
Brand Name :	Fair Machinery
Model Number :	FMP-01
Certification :	CE.ISO
Price :	900-1500 USD/set
Payment Terms :	T/T, Western Union, MoneyGram, L/C, D/A, D/P,Pyple
Supply Ability :	1000-2000 sets/month
Delivery Time :	3-7days

Add to Cart

Product Details
Company Profile

Waterproof Mortar Automatic Weighing And Packing Machine With Single / Double Mouth

Waterproof Mortar Automatic Weighing And Packing Machine With Single / Double Mouth

Application of Tile Adhesive Dry Mortar packaging machine

This kind of packing machine is widely used for filling and packing the dry powder materials, like: fly ash, coal powder, lime powder, mortar,cement and other materials.

Advantages of Tile Adhesive Dry Mortar Packing Machine
1. Automatic weighing and packing system, weighing accurately;
2. Small size and light quality, moving and installation conveniently;
3. Steady performance, easy to operate and maintenance;
4. High automation, labor-saving and increase efficiency.

Type: Other	Condition: New	Application: Chemical, construction material, dry mix mortar, Coating and other industries
Packaging Type: Bags, Stand-up Pouch, Other	Packaging Material: cement, powder, mortar, fine particles and so on	Automatic Grade: Automatic
Driven Type: Electric	Voltage: 380V/50HZ	Power: 3KW
Place of Origin: Henan, China (Mainland)	Brand Name:Fair Machinery	Model Number: FMP-01
Weight: 185kg	Dimension(LWH): 1070x670x1030	Certification: CE ISO
After-sales Service Provided: Engineers available to service machinery overseas	Name: Valve mouth packaging sand	Weighing Scope: 10~60kg, adjustable on panel.
Discharge Port Qty.: 1 pic	Capacity: 8-12 t/h	Motor Power: 3kw
Weighing device: Micro-computer	Packing speed: 3-5s per bag	Overall dimension(mm): 10706701030
Air Requirements: 0.4-0.8MPa ( dry compressed air)	Operating temperature: 0℃~50℃

The full automatic valve packaging machine is a weighing packing machine for powder. It is designed for dry-mixed mortar, concrete, chemical engineering etc. The machine’s microcomputer system adopt industrial grade components and STM process.

Item		FMP-01 valve bag packing machine
Weighing Scope		10~60kg, adjustable on panel.
Discharge Port Qty.		1 pic
Capacity		8-12 t/h
Motor Power		3kw
Measuring accuracy		±0.2-0.4％
Bag weight qualified rate		>95%
Weighing device		Micro-computer
Overall dimension(mm)		12006701200
Air Requirements		0.4-0.8MPa ( dry compressed air)
Application Environment	Operating temperature	0℃～50℃
	Storage temperature	-20℃～60℃

Components of full automatic valve bag packaging machine

Frame, Power head, Motor, Control cabinet, Gauge Outfit, Discharge Port, Pallet, Cylinder, Barometer, Discharging switch, Weight measuring system.

Working Principle of Automatic Valve Port Packing Machine

The automatic weighing and packing machine receives the weight of analog signal by gauge and sensor and convert to figure signal, to control contactor and solenoid vale by relay switching signal to achieve the motor rotation stop and air cylinder operation. The discharge principle is use high-speed rotation of the power head paddles make the material quickly set aside from the discharge port, the internal air blown inside the power head form a high pressure and puff away materials to help paddles disperse the material.
