Lime Valve Bag Packaging Machine Calcium Carbonate Valve Port Bag Packing Machine

Ask Lasest Price
Brand Name :	Fair Machinery
Model Number :	FMZZ-50FG
Certification :	CE,SGS,ISO
Price :	5000-12000 USD/set
Payment Terms :	T/T, Western Union, MoneyGram, L/C, D/A, D/P,Pyple
Supply Ability :	200-500 sets/month
Delivery Time :	3-7 days

Add to Cart

Product Details
Company Profile

Lime Valve Bag Packaging Machine Calcium Carbonate Valve Port Bag Packing Machine

Lime Valve Bag Packaging Machine Calcium Carbonate Valve Port Bag Packing Machine

Fair bag filling machine Specifications

Large capacity automatic valve bag packing machine is powder weighing packaging machine, specially designed for dry powder mortar,cement,chemical etc. The microcomputer system of this equipment produced by industrial-grade components using STM technology. It has the advantages of small volume, strong function, high reliability, good adaptability, etc., is a set of weighing and controlling in one machine. It has special capability of anti-jamming and can be long-term used in harsh environment

Application Materials(products)

Screw feeding type packing machine suit for pack powder of any industry,such as flour, starches, lime powder, cement, fertilizer,silica sand powder, nitrate of potash, ammonium sulfate etc

Application Bags(open mouth bags)

Our bagging machine is especially designed for pack materials(products) into open mouth bags,such as plastic woven bags,kraft bags,paper-plastic compound bags,sacks,barrel etc

Used in the pharmaceutical, chemical, pesticide, non-metallic, coatings, ceramics and other industries quantitative packaging. Such as: ceramic powder, calcium carbonate, wet powder, carbon black, rubber powder, food additives, pigments, dyes, zinc oxide, pharmaceutical powder.

Lime Valve Bag Packaging Machine Calcium Carbonate Valve Port Bag Packing Machine

Product Description

Fair valve bag filling machine is a non-bucket packing machine, which is made of closing valve, two lead screw, pneumatic jacket, weighing instrument, belt conveyor, baler and other components,

the material contact surface made of stainless steel.

Open-type packaging machine features: adopt artificial bagging, pneumatic folder bags, weighing process completed by the instrument control. Weighing after the seam, the use of skateboard to send bag and sewing machine with the synchronization effect is good, suture trajectory neat, to achieve the effect of the belt to send bag.

Features:

With folder bag weighing measurement, PLC control technology
The independent suspension sensors, signal transmission stability and ensure weighing accuracy
Host, conveyor belts, sewing charter, networking controller, ensure user-friendly operation and reduce labor intensity
The infrared sensor, gate control feeding materials, more energy saving
Weighing control system in accordance with IP54 (dust and water) requirements of the design

Technical parameters

Weighing scope: 20-50kg/bag
Precision level: ±0.5%
Packing speed: 300bag/hour
Working temperature: -20°C~+45°C

Our Services

* One year warranty
* Life time technique service support
* Provide consume spare parts at low price to old customer
* 24 hour phone service
