Single Shaft Ribbon Mixer Machine /Horizontal Feed Mixer For Mixing Raw Material

Ask Lasest Price
Brand Name :	Fair Machinery
Model Number :	FMZZ-15T
Certification :	CE, ISO
Price :	3000-35000 USD/set
Payment Terms :	T/T, Western Union, MoneyGram, L/C, D/A, D/P
Supply Ability :	1000sets/month
Delivery Time :	3-7 work days

Add to Cart

Product Details
Company Profile

Single Shaft Ribbon Mixer Machine /Horizontal Feed Mixer For Mixing Raw Material

Single Shaft Ribbon Mixer Machine /Horizontal Feed Mixer For Mixing Raw Material

Features of FIer Single shaft ribbon mixer

1. With CE certification

2. High mixing speed and short uniform time. Mixing speed is around 5-10mins/batch

3. All stainless steel 304 material or carton stell.

4. Full Mirror polished mixing tank inside, as well as ribbon and shaft.

5. Safety switch ,safety grid.

6. Castors for easy moving.

7. Technical discharge hole design to guarantee no material leaking.

Single Shaft Ribbon Mixer Machine /Horizontal Feed Mixer For Mixing Raw Material

Single Shaft Ribbon Mixer Machine Description

Fier horizontal Single Shaft Ribbon Mixer Machine, also known as Ribbon Blender.

It Is the use of mechanical force and gravity, two or more than two kinds of Powdery or granular material evenly mixed machinery.

Horizontal Feed Mixer can combine a variety of materials into a uniform mixture.

It can also increase the contact surface area of materials to promote chemical reactions. It also speeds up physical changes.

For example, granular solute added to the solvent, through the mixing machine can accelerate the dissolution of mixing.

It is suitable for a variety of dry powder, granular materials mixing.

Such as: putty powder, flour, plaster, dry mortar, feed, chemical materials, organic fertilizer and so on

Advantage of FAIR Single shaft ribbon mixer

1. The outer screw strip is 1-2mm from the gap of the cylinder wall, which not only avoids the wear of the cylinder wall, but also can well stir the materials around the cylinder wall that are not easy to stir.
2, horizontal structure, smooth operation, the material is not easy to enter the bearing caused damage to the stirring shaft, there are two horizontal O- type and horizontal U type to choose from!
4, cycloid needle reduction, maintenance rate is close to zero, low noise, avoid gear reduction putty powder mixer production process noise, belt often need to replace the trouble.
5, brand copper core motor, quality assurance.
6. High-quality steel plate material, durable, normal use of 8-10 years.
7. High production efficiency, uniformity up to over 98%.
8. Open the door to discharge materials and release them clean; The cleaning door is provided to facilitate clearance, which has little impact on the production of the next batch of different formula products

Single Shaft Ribbon Mixer Machine /Horizontal Feed Mixer For Mixing Raw Material

2. Technical Parameters of Single Shaft Ribbon Mixer Machine

Type(FMZZ-)	Power(kw)	Cylinder size(mm)	Dimension (mm) LWH
1T	5.5	Φ850×1250	2140x900x1325
2T	7.5	Φ1050×1875	2940x1300x1800
3T	11	Φ1050×3530	3315x1300x1800
5T	15	Φ1400×2500	3850x1700x2240
10T	22	Φ1600×3000	4400x1700x2560
15T	30	Φ1600×4200	5250x1850x2600
20T	37	Φ1850×4300	6250x1900x2545
30T	45	Φ2300×4500	6300x2300x3150
50T	50	Φ3500*5000	7500x2700x3200

Choose us!

We Fier Machinery are a professional manufacturer and supplier, and we are committed to providing good quality equipment of the ribbon mixer, Paddle Mixer, Powder Mixer, horizontal mixer as your requirement.

Within the present industrial mixing and packing business, Fier Machinery is holding a 63% market share in China and is developing more and more dealers across Europe and North America.

and also lots of successful projects are built and earning profit for our clients from Africa, South America, and Southeast Asia.

Choice us, build your brighter future!

Send a quote now!

Single Shaft Ribbon Mixer Machine /Horizontal Feed Mixer For Mixing Raw Material
