    One Axis Single Horizontal Shaft Mixer , Stainless Steel Ribbon Mixer CE Certified

    Ask Lasest Price
    Brand Name : Fair Machinery
    Model Number : FMZZ-100
    Certification : CE ISO
    Price : USD2500-24500/set
    Payment Terms : L/C, , T/T, Western Union, MoneyGram, D/A, D/P,Paypal
    Supply Ability : 500-1000set/month
    Delivery Time : 3-7 work days
    • Product Details
    • Company Profile

    One Axis Single Horizontal Shaft Mixer , Stainless Steel Ribbon Mixer CE Certified

    One Axis Single Horizontal Shaft Mixer , Stainless Steel Ribbon Mixer CE Certified


    Fair dry powder mixer machine features:


    1, our powder mixer machine material: ordinary carbon steel, SUS304 stainless steel, 316 l stainless steel variety of equipment materials for user to choose from, meet different product health, corrosion and wear resistant requirements;
    2: coulter type mixing mechanism of the new concept of the use of core technology, combined with high speed rotating cutter discrete type mixing, mixing speed;
    3: horizontal simplified by material, simplified upside sets inlet, observation hole, simplified has material cleaning door opening on one side; According to process need
    4: heat insulation device: can do jacket or coil heat transport, external thermal insulation device can do.

    One Axis Single Horizontal Shaft Mixer , Stainless Steel Ribbon Mixer CE Certified

    Fair dry powder mixer working Introduction:

    Dry powder mixer which is made by Fair Machinery,it is made of transmission part, stirrer,round barrel,high speed cutter.
    After the machine start,the coulters will rotate by colter axis,the material will be move along the barrel,At the same time on both sides of the material along the coulter surface normal direction .

    Materials can also be driven along the circular simplified as a circular flow, In the middle of the high-speed fly knife for mixing and depolymerization of of agglomerate dispersion of auxiliary function, material in ploughshares and fly knife can achieve more in a short period of time under the dual function of mixing of powder and fiber dispersion effect is particularly obvious, mixing uniformity is good.

    Can also according to customer's need to customize :

    A: according to different product requirements can be designed different cylinder: O barrel, U barrel, etc.

    2: according to different material performance can choose different mixing blades: two-way coulter form/one-way blade form.

    Overview


    Condition: New

    Mixer Type: Screw

    Product Type: dry mortar powder mixing machine

    Application: Powder

    Additional Capabilities:has viewing port

    Place of Origin: Henan, China (Mainland)

    Brand Name: Fair Machinery

    Model Number: FMZZ-100

    Max. Loading Capacity: 1000L

    Voltage: 220V/380V

    Power(W): 1.5KW

    Dimension(L*W*H):according to the type

    Certification: ISO9001,CE

    Warranty: 2Year

    After-sales Service Provided: Engineers available to service machinery overseas

    Name: Dry powder mixer machine

    Machine Type: Dry powder mixer machine

    Price: Competitive

    Capacity: 500L

    ODM/OEM: YES

    Color: Ceramic or upon customers' demand

    Function: mixing dry mortar powder and other raw materials

    Feature: low residue,low noise,high speed,has viewing port

    Advantage: low investment,covinent installation


    Packaging & Delivery

    Packaging Details

    container transport
    client's packing requirement or packing by wooden case

    Delivery Time

    10DAYS AFTER PAYMENT

    One Axis Single Horizontal Shaft Mixer , Stainless Steel Ribbon Mixer CE Certified


    Technical data of industrial blender

    Model

    FMZZ-100

    FMZZ-200

    FMZZ-300

    FMZZ-500

    FMZZ-1000

    FAZZ-2000

    FMZZ-3000

    FMZZ-5000

    Volume M3

    0.5

    1

    2

    3

    4

    5

    6

    8

    Single capacity KG

    300

    650

    1200

    1800

    2400

    3000

    3600

    4800

    Speed

    56

    46

    46

    46

    46

    46

    46

    46

    Power KW

    1.5KW

    2.2KW

    3KW

    5.5KW

    7.5KW

    11KW

    15KW

    18.5KW

    Weight kg

    900

    2300

    3500

    4300

    6500

    7600

    8200

    11000

    Length

    1390

    1930

    2235

    2640

    3160

    3520

    3425

    4255

    Wideth

    570

    625

    760

    950

    1150

    1350

    1480

    1820

    Height

    1020

    1210

    1450

    1795

    2005

    2255

    2370

    2935
