Industrial Horizontal Ribbon Mixer Powder Mixer Dry Poultry Cattle Feed Mixer

Ask Lasest Price
Brand Name :	Fair Machinery
Model Number :	FMZZ-2T
Certification :	ISO9001,CE
Price :	3000-35000 USD/set
Payment Terms :	T/T, Western Union, MoneyGram, L/C, D/A, D/P
Supply Ability :	1000sets/month
Delivery Time :	3-7 work days

Add to Cart

Product Details
Company Profile

Industrial Horizontal Ribbon Mixer Powder Mixer Dry Poultry Cattle Feed Mixer

Industrial Horizontal Ribbon Mixer Powder Mixer Dry Poultry Cattle Feed Mixer

Feed Mixer Description

The Feed Mixer is widely used in chemical, pharmaceuticals, food, and construction line.

It can be used to mix powder with powder, powder with liquid, and powder with granule.
Under the driven of motor, the double ribbon agitator mix the material quickly.

Our Feed Mixer is easy use and maintains and clean, small occupies, high efficient and long service life; Industry mixer machine is specialized in blending the resin emulsion with different gradations of sand particles.

Feed Mixer Working principle:

The outer ribbon push the material from the two ends to the centre, inner ribbon push the material from center to the two ends.Thus to achieve material convention
The discharging port is set in the bottom centre, with the help of the outer ribbon,the material can be discharged completely, and no dead zone.

2. Technical Parameters of Feed Mixer

Type(FMZZ-)	Power(kw)	Cylinder size(mm)	Dimension (mm) LWH
1T	5.5	Φ850×1250	2140x900x1325
2T	7.5	Φ1050×1875	2940x1300x1800
3T	11	Φ1050×3530	3315x1300x1800
5T	15	Φ1400×2500	3850x1700x2240
10T	22	Φ1600×3000	4400x1700x2560
15T	30	Φ1600×4200	5250x1850x2600
20T	37	Φ1850×4300	6250x1900x2545
30T	45	Φ2300×4500	6300x2300x3150
50T	50	Φ3500*5000	7500x2700x3200

Note

The capacity can be adjusted according to user requirement.

Industrial Horizontal Ribbon Mixer Powder Mixer Dry Poultry Cattle Feed Mixer

3. Fier feed mixer features:

Options for motor: general motors, explosion-proof motors, variable frequency motor, high efficiency and energy saving motor.
Commonly used reducers: R-series, K-series, and F-series gear box; cycloidal reducer, universal gear reducer, planetary gear reducer.
Commonly motor-gearbox connection: direct connection, pulley connection, hydraulic coupler connection.

Various inlets on the top cover of the barrel can be designed according to different situations.
They can be used as man hole, cleaning door, feeding hole, vent, and dust colleting hole.
The top cover can be designed as fully-opened lid for easy cleaning.
Mixer is frequently equipped with many auxiliary components, like steam coil jacket, honeycomb pressure jacket, medium circulation jacket
sampling valve, high speed chopper, temperature sensor, weighing system, dust removal system and so on.
Different heat medium requires different jacket, it can be used for heating and cooling, while, the temperature should be within 250 Celsius degree.

Electrical control board;
Safety joint having a torque limiter function;
Support frame for lifting the load from the ground;
Load cell-weighing system that can weigh several different ingredients and formulas for managing the batching process in a precise and reliable manner;
Fitted for loading or unloading with GIMAT flexible spiral or rigid screw systems;
Customized versions to meet specific needs.
