    Ribbon Type Fine Powder Mixer / Food Powder horizontal Mixer Machine SGS Approved

    Ask Lasest Price
    Brand Name : Fair Machinery
    Model Number : FMZZ-500
    Certification : CE, ISO, SGS
    Price : USD2500-24500/set
    Payment Terms : L/C, , T/T, Western Union, MoneyGram, D/A, D/P,Paypal
    Supply Ability : 500-1000set/month
    Delivery Time : 3-7 work days
    • Product Details
    • Company Profile

    Ribbon Type Fine Powder Mixer / Food Powder horizontal Mixer Machine SGS Approved

    Ribbon Type Fine Powder Mixer / Food Powder horizontal Mixer Machine SGS Approved

    Fair powder mixer introduction:

    Powder mixer is a new type of high efficient mixing equipment,

    widely used in dry mortar, putty powder, powder, medicine, food, feed, chemical, ceramics, refractory materials and other mixed powder, chemical industry, compound fertilizer, fuel, paints, rubber, building materials, refractory materials, rare earth new materials, nuclear materials, plastic and glass industry solid - solid - solid (i.e., powder and powder), plasma (i.e., powder and rubber slurry) logistics mix.

    Overview

    Condition: New

    Mixer Type: Screw

    Product Type: dry mortar powder mixing machine

    Application: Powder

    Additional Capabilities:has viewing port

    Place of Origin: Henan, China (Mainland)

    Brand Name: Fair Machinery

    Model Number: FMZZ-500

    Max. Loading Capacity: 1000L

    Voltage: 220V/380V

    Power(W): 5.5KW

    Dimension(L*W*H): 2640*950*1795mm

    Certification: ISO9001,CE

    Warranty: 2Year

    After-sales Service Provided: Engineers available to service machinery overseas

    Name: Dry powder mixer machine

    Machine Type: Dry powder mixer machine

    Price: Competitive

    Capacity: 500L

    ODM/OEM: YES

    Color: Ceramic or upon customers' demand

    Function: mixing dry mortar powder and other raw materials

    Feature: low residue,low noise,high speed,has viewing port

    Advantage: low investment,covinent installation

    500kg/batch dry powder mixing machine
    1. CV≤ 7%.
    2. Mixing time 3-6 minutes.
    3. Capacity: 5-6 batch/hour. It means capcity= 2.5-3 t/h.


    The mixing action in the dry mortar ribbon blender is created by the following 3 factors:

    • Conveying of product by one ribbon from left to right

    • Counter flow of product by the second ribbon

    • Exchange of product between the two ribbons

    Ribbon Type Fine Powder Mixer / Food Powder horizontal Mixer Machine SGS Approved

    Technical data

    Model

    FMZZ-100

    FMZZ-200

    FMZZ-300

    FMZZ-500

    FMZZ-1000

    FAZZ-2000

    FMZZ-3000

    FMZZ-5000

    Volume M3

    0.5

    1

    2

    3

    4

    5

    6

    8

    Single capacity KG

    300

    650

    1200

    1800

    2400

    3000

    3600

    4800

    Speed

    56

    46

    46

    46

    46

    46

    46

    46

    Power KW

    1.5KW

    2.2KW

    3KW

    5.5KW

    7.5KW

    11KW

    15KW

    18.5KW

    Weight kg

    900

    2300

    3500

    4300

    6500

    7600

    8200

    11000

    Length

    1390

    1930

    2235

    2640

    3160

    3520

    3425

    4255

    Wideth

    570

    625

    760

    950

    1150

    1350

    1480

    1820

    Height

    1020

    1210

    1450

    1795

    2005

    2255

    2370

    2935


    Optional Features of dry powder mixer
    ------Material: Carbon Steel, Stainless Steel 304, Stainless Steel 316L
    ------Explosion-proof motors
    ------Controls such as variable frequency drives, motor starters and operator stations are available
    ------Spray nozzles for adding liquid.

    We also can design dry mortar production line including horizontal mortar mixer, spiral conveyors and stock bin.
