High-viscosity Paint Blender Equipment Stone Finish Paint Mixing Machine For Liquids

Ask Lasest Price
Brand Name :	Fair Machinery
Model Number :	FMZZ-5T
Certification :	ISO9001:2008
Price :	3000-35000 USD/set
Payment Terms :	T/T, Western Union, MoneyGram, L/C, D/A, D/P
Supply Ability :	1000sets/month
Delivery Time :	3-7 work days

Add to Cart

Product Details
Company Profile

High-viscosity Paint Blender Equipment Stone Finish Paint Mixing Machine For Liquids

High-viscosity Paint Blender Equipment Stone Finish Paint Mixing Machine For Liquids

Features of Horizontal Ribbon Mixer for lacquer painting

1. It is suitable for mixing materials of powder-powder and power-liquid, especially for paste,powder and thick materials, such as putty, stone coatings, metal powders etc.

2. It is a new type of mixing equipment with high efficiency, high uniformity, high load factor,low energy consumption, low pollution and little destruction to frangible material.

3. The major sections of a mixer are barrel, ribbon agitators, feeding ports, discharging port and driven unit.

4. Double ribbon mixer drive the material from two ends to centre through the help of the outer ribbon, while the inner ribbon push the material from centre to two ends, thus, material achieve a high mixing effect at short time.

5. The ribbon mixer can be equipped with heating or cooling jacket if temperature control is required. We will add spraying or atomizing unit inside the tank.

Product Description of lacquer painting mixer

Fier dry mortar mixer machine is mainly composed of the body, rotor, transmission and control parts.

Uses:

Suitable for mixing powdered or granular materials. Mainly used for feed mills, chemical industry, dry mortar industry, food industry and so on.

lacquer painting mixer Features:

Mixing moderate and high uniformity, mixing uniformity CV≤7%, no segregation.

Short mixing cycle(180-240s), large open layout, a quick feed, a small amount of residue.

Atomizing nozzle configuration stainless steel, to meet the needs of adding the liquid.

Our company mixing machines is easy use and maintains and clean, small occupies, high efficient and long service life; dry mortar mixer machine is specialized in blending the resin emulsion with different gradations of sand particles.

Good quality, competitive price and excellent after-sale service are highly praised by customers.

So far, product sales have covered more than 25 provinces and cities in China and also exported to Ghana, Botswana, Benin, Ivory Coast, Venezuela, Mozambique, Indonesia, Malaysia, Korea and over more than 20 ountries.

2. Technical Parameters of lacquer painting mixer

Model	Single Agitation(Ton)	Power (kw)	Cylinder size(m)	Dimensions(m)
FM-1	1t	5.5kw	850*1250	2.20.91.7
FM-2	2t	7.5kw	1150*1500	2.61.32.1
FM-3	3t	11kw	1150*1875	3.01.32.1
FM-5	5t	18.5kw	1250*2500	3.91.42.2
FM-10	10t	22kw	1600*3000	4.41.72.7
FM-20	20t	37kw	1850*4500	6.31.92.6
FM-30	30t	45kw	2300*4500	6.52.33.2

The capacity can be adjusted according to user requirement.

Terms of price: FOB CIF CFR

Packaging term: nude cargo OR wooden case

Terms of Payment: T/T, L/C AT SIGHT, WEST UNION

Time of delivery: 7 days after receiving deposit

MOQ: 1 SET

If you are interested in our ddry mortar mixer, there are some details to confirm:

1. what's your raw material?

2. the capacity per hour?

3. Is the putty mixer matched with feed line? Any special requirement about the inlet size and discharge model?

Why us

lacquer painting mixer is a late-model mixing equipment with high efficiency, high uniformity, high loading coefficient but low energy cost, low pollution and low crush.

The special design of double ribbon mix the materials into high uniformity in a few minutes.

On the other hand, ribbon mixer shows a wide application from powder mixing , powder-liquid, to paste or materials in high specific gravity (such as putty, really stone paint, metal powder and other materials) and becomes one of the most popular single shaft horizontal mixing equipment.
