Ores Sepiolite Vertical Raymond Mill Pulverizer Grinding Mill
Machine
Raymond Mill Pulverizer Working Principle
The working process of the whole Raymond Mill Pulverizer: After the
bulk material is crushed to the required particle size by the jaw
crusher, the material is sent to the storage hopper by elevator,
and then the material is continuously fed in evenly and
quantitatively through the vibrating feeder Grinding in the main
machine grinding chamber, the ground powder is taken away by the
airflow of the fan, and
classified by the analyzer. The fineness of the powder enters the
large cyclone collector through the pipe with the airflow for
separation and collection, and then the powder is discharged The
valve discharge is the finished powder. The airflow is sucked into
the blower by the return duct at the upper end of the large cyclone
collector. The entire airflow system of this machine is closed and
circulating, and it circulates under the condition of positive and
negative pressure.
Advantages of Raymond Mill Pulverizer
High capacity, 1-20t/h.
The fineness can be adjusted between 50 and 325 mesh (315-45
micron).
Fixed with 1000-1500kg pressure springs, and its capacity increase
20% to 30%; When the grinding roller and grinding ring, stable
capacity and fineness can be guaranteed.
Easy maintenance, simple structure, low investment
Environment-friendly. Application of pulse bag filter & muffler
greatly alleviates dust pollution and noise.
Main technical parameters of FAIR Raymond mill machine
| Type | Roller | Max. feeding size(mm) | Fineness of product(mm) | Output (t/h) | Power of machine(KW) | Size(mm) |
| Quantity(pieces). | Dimension(mm) | Height(mm) |
| YGM7815 | 3 | 260 | 150 | 15 | 0.613-0.033 | 1-3 | 18.5 | 4300*3500*5100 |
| YGM8314 | 3 | 270 | 140 | 20 | 0.613-0.033 | 1.2-4.6 | 22 | 5300*4100*5200 |
| YGM9517 | 4 | 310 | 170 | 25 | 0.613-0.033 | 2.1-5.6 | 37 | 7100*5900*7900 |
| YGM4121 | 5 | 410 | 210 | 30 | 0.613-0.033 | 2.8-10.5 | 75 | 9200*7250*9700 |
| MTM1600 | 6 | 440 | 270 | 35 | 0.613-0.033 | 5-20 | 132 | 12550*5700*8350 |
Raymond Mill Pulverizer Details
FAQ:
Q1: Does your company supply the spare parts?
A: Yes, we supply the spare parts for your stone crusher plant.
Q2: What details should customers send to us before we provide the
equipment list and quotation?
A: 1) The materials to be processed? quartz, talc, etc.
2) The maximum size of the stone before grinding?
3) The expected handling capacity? ton per hour or ton per day
Q3: If I plan to build a complete grinding mill, can your company
provide technical support?
A: Yeah, senior technical engineers will assigned to provide
installation guidance, commissioning, etc. for your project.
Q4: What is your payment method? Does you company support Trade
Assurance on Alibaba?
A: T/T, Letter of Credit, Western Union, etc are available.
Moreover, the Trade Assurance on Alibaba is okay.
Q5: Can the products be delivered to the Qingdao port, Shanghai
Port, Urumqi, Guangzhou, Dali, etc?
A: Sure, the products can be delivered to the destination as
required.
